Flat Panel Ceiling Lift with vertical motion and rotation FPLCV2-90+R+LM+LOCK

FPLCV2-90+R+LM+LOCK

Unitech Systems transforms the customized solutions for big TVs in a new standard model of TV ceiling lift: the new FPLCV2+R+LM+LOCK-90, suitable for TVs between 75”-90”. Silent, safe & ready to install, this new heavy duty ceiling lift, offers a complete set of functions such as: vertical lowering motion, bi-directional rotation ±180o, ensuring maximum safety in closed position . The lift’s solid & firm construction provides maximum duration in time & safety in installation, in addition to its excellent utility! FPLCV2+R+LM+LOCK-90 has been selected for the short list of 2016 InAVation Awards - Technology Finalists.

Features

Maximum flat panel dimensions (WxHxD) ≤ 2060x1170x120mm
Maximum load : TV weight ≤ 65kg and ceiling cover ≤ 30kg
Lift dimensions (WxHxD) 2801x395x2215mm (excluding control box)
Lift weight: ~550kg
Maximum swiveling angle 90degrees
Vertical lowering motion 1225mm
Rotation ability (CW & CCW) +/-180degrees both ways : 180o CW & 180o CCW
Adjustable hole pattern for flat panel mounting (vesa) up to 800x600mm
Standard color of metallic parts: powder coating in RAL 9005 black or RAL 9016 white

Specifications

Maximum flat panel dimensions (WxHxD) ≤ 2060x1170x120mm
Maximum load : TV weight ≤ 65kg and ceiling cover ≤ 30kg
Lift dimensions (WxHxD) 2801x395x2215mm (excluding control box)
Lift weight: ~550kg
Maximum swiveling angle 90degrees
Vertical lowering motion 1225mm
Rotation ability (CW & CCW) +/-180degrees both ways : 180o CW & 180o CCW
Adjustable hole pattern for flat panel mounting (vesa) up to 800x600mm
Standard color of metallic parts: powder coating in RAL 9005 black or RAL 9016 white
Power supply wire control at 230VAC
Standard control option: dry contacts control box
Optional controls: RF remote control or RS 232 ports
